Stainless steel horizontal centrifugal pump

Short Description:

●The stainless steel pump adopts precision dewaxing casting, the inside and outside of the pump are balanced and smooth, there is no sand hole phenomenon, and the size is high.

●Stainless steel SUS304, 316, 316L, titanium metal casting, suitable for use in various acid-base, high temperature, corrosive media and environments.

●The impeller is corrected by dynamic balance, low vibration and low noise.

●Equipped with TECO motor, a Taiwanese brand, durable.

Send email to us

Product Detail

Product Tags

Model Description

ZJ	--50	--2	--S	--6	--V	--5
Model	Inlet and outlet diameter	Horsepower	Material of shaft seal	Pump material	O-ring material	Frequency
Model number: ZJ	Entrance and exit diameter:25-1" 40-1.5" 50-2" 65-2.5" 80-3" 100-4" 125-5" 150-6"	Horsepower: 0.5-0.5HP 1-1HP 2-2HP 3-3HP 5-5HP 7.5-7.5HP 10-10HP 15-15HP 20-20HP 25-25HP 30-30HP 40-40HP	Material of shaft seal:S-Sic T-Tungsten steel alloy	Pump material:4-SUS3046-SUS316	O-ring material: N-NBR E-EPDM V-VITON	Frequency:5-50Hz 6-60Hz
